1.Main Features:
* Android 9.0 Systems, 4G & WiFi Connection
* CPU: MT6761 ARMCortex-A53, 2.0GHz
* Memory: LPDDR4 1GB RAM / 4GB ROM
* Storage: Micro SD Card, Max 256GB
* H.264, Full HD 1080P, 30fps
* Ultra wide 145 degree viewing angle captures more of the road around you
* 4G+WiFi, Live view remotely by APP or tracking platform with two way audio communication
* Enjoy Free GPS Tracking services
* Support SOS Alarm and Parking Monitor with Time-Lapse Photography, with Low Battery Protection
* Alarm report, History tracking report, lgnition on/off report, Mileage report
* Vibration alarm, Anti-theft alarm, Geofence alarm, Over-speed alarm
2.Specification:
4G Car DVR / 4G LTE Car DVR |
Model | iSV-E12 |
Hardware | CPU | MT6761 ARMCortex-A53, 2.0GHz (Quad Core) |
OS | Android 9.0 |
RAM | LPDDR4 1GB RAM |
Memory | Flash 4GB |
Micro SD Card | Max 256G |
Rear Camera | HD 1080P (Default) |
Interface | BMW wire interface |
Network / Data | Network | FDD-LTE(4G), WCDMA(3G), GSM900/1800 |
4G Frequency | FDD-LTE B1/B3/B8 |
3G Frequency | WCDMA B1/B8 |
GPS Location | GPS, A-GPS, BeiDou |
Data Service | HSDPA, HSPA+, LTE |
Main Functions | GPS Tracker | Support, App & PC Platform |
DVR | Full HD 1080P with 30fps, Loop-Recording |
Cameras | Forward Camera: 1080P, adjustable viewing angle 145° |
Rear Camera: 1080P, viewing angle 135° |
Wi-Fi | 802.11b/g/n (WLAN), 2.4G |
Bluebooth | Optional |
G-Sensor | Support |
TS Streaming | Support, TS Streaming Record |
MIC & Speaker | Support Dual-way Talking |
Remote Monitoring | App & Platform, Remote Video and Remote Image |
Playback | Support APP playback with WiFi and Remotely |
Live View | P2P Live View, Front-Car/Rear-Car Live Video streaming Via APP |
History Tracking Playback | Support One Month |
SOS Alarm | Support |
Vibration Alarm | Support |
Anti-theft alarm | Support |
Over-speed Alarm | Support |
Geofence Alarm | Support |
Park Monitoring | Support Time-Lapse Photography |
Platform Report | History tracking report, Ignition on/off report, Alarm report |
Power Supply | Support DC24-48V input |
Others | Operating Temperature | -20℃~70℃ |
Operating Humidity | 0~90%, Non-Condensed |
Dimension(L*W*H) | 110(L)*90(W)*30(H)mm |
3. Mobile APP Preview and Setting:
Installation:
