1. Features:
* 4G & WiFi Connection, 4K (3840x2160) Resolution
* 4G Module, Cortex A53 1.2GHz(4 Core) IPU, Linux4.19 System
* Sony IMX415 Sensor, 8.0Mega Pixels
* H.265, 4K+1080P+1080P Three Channels, 30Fps, MP4
* WDR, Super Night Vision, with G-Sensor
* Maximum Support 512GB SD Card
* 4G+WiFi, Live Video Remotely by App or PC Platform
* Ultra wide 158°View Angle captures more of the road around you
* Enjoy Free GPS Tracking Services
* Support Parking Monitor, Support Time-Lapse Record
* Support Low Battery Protection
* SOS Alarm, Collision Alarm, Anti-Theft Alarm, Geo-fence Alarm, Over-speed Alarm
2. Specification:
4G&4K 3CH Dash Cam |
Model | iSV-T3 |
Hardware | 4G Module | Europe / American Module |
IPU | Cortex A53 1.2GHz(4 Core) |
Sensor | Sony IMX415 Sensor / 8.0Mega Pixels, WDR, Super Night Vision |
OS | Linux 4.19 |
DDR | 256MB |
Memory | Flash 128MB |
Micro SD Card | Max 512GB |
Rear Camera | Optional |
Button | ON/OFF |
IPS Screen Size | Optional, 3.18” Touch Screen |
Network / Data | 4G/3G Network | LTE-FDD/LTE-TDD(4G), WCDMA(3G) |
FDD-LTE: B1/B3/B5/B7/B8/B20/B28, TDD-LTE: B38/B40/41 |
Data Service | LTE, WCDMA, HSDPA, HSUPA |
GPS Location | GPS / GLONASS / BDS |
Wi-Fi | 2.4G/5G, WLAN |
Main Functions | DVR | H.264, 4K(Front)+1080P(In-Cabin)+1080P(Rear) with 30fps, Loop-Recording |
WDR | Support |
Super Night Vision | Support |
GPS Tracking | Support, App & PC Platform |
G-Sensor | Support |
Remote Monitoring | App & PC Platform, Remote Video and Remote Picture |
Playback | Support App playback with Wi-Fi and Remotely |
Live Streaming Video | P2P or RTMP Live View Front-Car/Rear-Car/In-Cabin Live Streaming Video Via APP or PC Platform |
Cameras | Front Cam: SONY IMX415, UHD 4K, Adjustable viewing angle 158° |
In-Cabin Cam: SC235HAi, 1080P, Viewing angle 140° |
Rear Cam: GC2053, 1080P, Viewing angle 145° |
MIC & Speaker | Support Dual-way Talking |
Micro SD Card | Support Max 512GB |
Time-Lapse Record | Support, 8H / 12H / 24H / 48H Optional |
Low Battery Protection | Support |
Parking Monitoring | Support |
SOS Alarm | Support |
Anti-Theft Alarm | Support |
Geofence Alarm | Support |
Over-speed Alarm | Support |
Others | Operating Temperature | -20℃~70℃ |
Operating Humidity | 0~90%, Non-Condensed |
Dimension(L*W*H) | 115(L)*58 (W)*32(H)mm |
